| ULTRA HIGH RESISTANCE VALUES HERMETICALLY SEALED IN GLASS |
|||||
| FEATURES |  |
||||
| Ultra high values | |||||
| Impervious to moisture | |||||
| Resistance tolerances to 5% | |||||
 |
|||||
| SPECIFICATIONS | |||||
| Resistance Range: 10 Meg to 100T | |||||
| Maximum Operating Voltage: 600 | |||||
| Power Rating: .5 Watt @ 25°C | |||||
| Operating Temperature: -40°C to +70°C | |||||
| Resistive Element: Carbon Complex Thick Film | |||||
| Shelf Life: < 0.5% Resistance Change/Year | |||||
| TEMPERATURE COEFFICIENT | |||
| RESISTANCE VALUE | PPM/°C | RESISTANCE TOLERANCES (%) | |
| 10M - 100M | -1500 | 5 TO 20 | |
| 100M - 100T | -2000 | 10 TO 20 | |
| HOW TO ORDER | EXAMPLE: 500MEG 5% | ||||
| RX50 | 500 | 6 | J | * 5% = J | |
| STYLE | RESISTANCE | NO. of ZEROS | *TOLERANCE | 10% = K | |
| 20% = M | h | ||||
